Mountz BMX1000F Torque Reaction Transducer, Range 100 - 1000 Lb-ft, Drive Size 1", # 077015
The Mountz BMX1000F Torque Reaction Transducer, Range 100 - 1000 Lb-ft, Drive Size 1", # 077015 is ideal for calibrating hand screwdrivers, wrenches, and power tools.
RS-232 and Mitutoyo (Digimatic) outputs Accuracy .25% of full scale ( 0.5% for 10,000F & 20,000F models) Female square drive Bi-directional measurement Mounting brackets available, optional
Rated Output
2mv/v Nominal
Safe Overload
125% of Rated Output
Bridge Resistance
350 Ohms Nominal
Nonlinearity
± .1% of Rated Output
More Information
Product Specifications
Rated Output
2mv/v Nominal
Safe Overload
125% of Rated Output
Bridge Resistance
350 Ohms Nominal
Nonlinearity
± .1% of Rated Output
Product Features
RS-232 and Mitutoyo (Digimatic) outputs Accuracy .25% of full scale ( 0.5% for 10,000F & 20,000F models) Female square drive Bi-directional measurement Mounting brackets available, optional
