Shimpo MCS-3109 NPN (NO,NC) Output, 300 Hz Frequency, 0.32" Sensing Distance, 6.5" Cable, NEMA 6 (IP67) Rating, for Use in High Vibration Areas
The Shimpo MCS-3109 NPN (NO,NC) Output, 300 Hz Frequency, 0.32" Sensing Distance, 6.5" Cable, NEMA 6 (IP67) Rating, for Use in High Vibration Areas is complimentary (NPN-NO and NPN-NC) proximity sensor normally used in high-vibration areas and where a greater sensing distance is required.
NPN (NO, NC) output 300 Hz frequency 0.32" (8 mm) sensing distance 6.5' (2 m) cable NEMA 6 (IP67) rating, for use in high vibration areas
Sensing Distance
8 mm (0.32")
Activating Frequency
300 Hz
Voltage Requirement
10 – 30 VDC
Output Current
100 mA
Housing
Nickel plated brass
Ambient Temperature
-25 to 70 °C (-13 to 158 °F)
Degree of Protection
IP67 / NEMA 4
More Information
Product Specifications
Sensing Distance
8 mm (0.32")
Activating Frequency
300 Hz
Voltage Requirement
10 – 30 VDC
Output Current
100 mA
Housing
Nickel plated brass
Ambient Temperature
-25 to 70 °C (-13 to 158 °F)
Degree of Protection
IP67 / NEMA 4
Product Features
NPN (NO, NC) output 300 Hz frequency 0.32" (8 mm) sensing distance 6.5' (2 m) cable NEMA 6 (IP67) rating, for use in high vibration areas
