The Western Instruments N88-9B Basic Bridging Pit Depth Gauge, Measures Corrosion and Material Loss is used to measure Dents and Buckles on Pipelines, Shell Settlement on Storage Tanks, etc. Bridging Pit Gauges take over where the capabilities of our standard Pit Gauges fall short, for evaluating large areas of Weight loss Corrosion.
Used to measure Dents and Buckles on Pipelines, Shell Settlement on Storage Tanks, etc
These various forms of Bridging Bars can utilize any of our exclusive Dial Indicators (Imperial, Metric, or Digital), with any of our Custom Engineered Contact Points
N88-9 Bridging Pit Gauge Indicator (Inch, Metric or Digital)
N88-9-1 Main Blade - Center and End Dial Indicator Mounting Positions, Fitted Permanent Magnets. Cutaway Nose for next to welds. 5.5u201d (144mm) long.
N88-9-7 Fastener Kit (Hardware) - Fasteners, Allen Key, Nylon Thumb Screws, #1 Contact Point-Standard.
N88-9-8 Carrying Case - Hard Sided Plastic Carrying Case for entire kit
Main Blade,l Indicator, Connector Blade, 2-Extender Tees, End Blade, Slider Blade, Hardware, Extra Contact Point, and Carrying Case
Product Features
Used to measure Dents and Buckles on Pipelines, Shell Settlement on Storage Tanks, etc
These various forms of Bridging Bars can utilize any of our exclusive Dial Indicators (Imperial, Metric, or Digital), with any of our Custom Engineered Contact Points
